H229 Series Portable Cylinder Regulator

Compact, fixed flow, pistion sensed, regulator for calibration gases and industrial hygiene.

Features

Compact Size: ( 1-1/8" W x 3-3/8" H )

Factory Preset Flowmeters: 0.25 - 6.0 slpm

Hose Barb Outlet: 3/16"

Control Knob: On/Off

Maximum inlet pressure: 1000 psi ( 70 bar )

Preset Delivery Pressure: 50 psi ( 3 bar )

Weight: 0.66 lb ( 0.3 kg )

Dimensions

Ordering Information

Series	Model Number	Inlet Connection	Outlet Connection	Inlet Pressure	Material	Flow
H229A	H229A-0.25 H229A-0.5 H229A-1.0 H229A-1.5	CGA600 CGA600 CGA600 CGA600	3/16" Hose Barb 3/16" Hose Barb 3/16" Hose Barb 3/16" Hose Barb	500 psi 500 psi 500 psi 500 psi	Chrome-Plated Brass Chrome-Plated Brass Chrome-Plated Brass Chrome-Plated Brass	0.25 slpm Air 0.5 slpm Air 1.0 slpm Air 1.5 slpm Air
H229B	H229B-0.25 H229B-0.5 H229B-1.0 H229B-1.5 H229B-2.5 H229B-6.0	5/8"-18UNF ( C-10 ) 5/8"-18UNF ( C-10 ) 5/8"-18UNF ( C-10 ) 5/8"-18UNF ( C-10 ) 5/8"-18UNF ( C-10 ) 5/8"-18UNF ( C-10 )	3/16" Hose Barb 3/16" Hose Barb 3/16" Hose Barb 3/16" Hose Barb 3/16" Hose Barb 3/16" Hose Barb	1000 psi 1000 psi 1000 psi 1000 psi 1000 psi 1000 psi	Chrome-Plated Brass Chrome-Plated Brass Chrome-Plated Brass Chrome-Plated Brass Chrome-Plated Brass Chrome-Plated Brass	0.25 slpm Air 0.5 slpm Air 1.0 slpm Air 1.5 slpm Air 2.5 slpm Air 6.0 slpm Air
H229S	H229S-0.25 H229S-0.5 H229S-1.0 H229S-1.5 H229S-2.5 H229S-6.0	5/8"-18UNF ( C-10 ) 5/8"-18UNF ( C-10 ) 5/8"-18UNF ( C-10 ) 5/8"-18UNF ( C-10 ) 5/8"-18UNF ( C-10 ) 5/8"-18UNF ( C-10 )	3/16" Hose Barb 3/16" Hose Barb 3/16" Hose Barb 3/16" Hose Barb 3/16" Hose Barb 3/16" Hose Barb	1000 psi 1000 psi 1000 psi 1000 psi 1000 psi 1000 psi	Stainless Steel Stainless Steel Stainless Steel Stainless Steel Stainless Steel Stainless Steel	0.25 slpm Air 0.5 slpm Air 1.0 slpm Air 1.5 slpm Air 2.5 slpm Air 6.0 slpm Air
