GENTEC R63 Series Dome Loaded Regulator
R63 Series Dome Loaded Regulator
GENTEC R63 Series Dome Loaded Regulator uses external pressure source to control the outlet pressure. The R63 regulator is suitable for applications demanding high flowrates while maintaining a stable outlet pressure.
Features
Dome Loaded Regulator minimizes droop
Dynamic pressure control
High Pressure, High Flow
1" NPT connections
Dimensions
GENTEC R63 Series Dome Loaded Regulator
Flow Data
GENTEC R63 Series Dome Loaded Regulator
Ordering Information
订购指南
EX: R63SL
Series		 A
Body Ports		 K
Seat Material		 - F
Inlet Pressure		 K
Outlet Pressure		 P
Gauge		 - 08
Inlet Connections		 - 08
Outet Connections		 - R44
Options
R63SL A
B
G
J
K
K: PCTFE
D: 3000 psi (206 bar)
F: 500 psi (34 bar)
E: 0~1500 psi (103 bar)
F: 0~500 psi (34 bar)
G: 0~250 psi (17 bar)
H: 0-150 psi (10 bar)
I: 0~100 psi (7 bar)
K: 0~50 psi (3 bar)
L: 0~25 psi (1.5 bar)
P: psi / bar
K: psi / kPa
W: No Gauge
08: 1" NPT ( F )
Other connections
available*
08: 1" NPT ( F )
Other connections
available*
None: Without Regulator
R44: With Control Regulator
( 500 ~ 1500 psi )
R21: With Control Regulator
( < 500 psi )

*: More inlet connection options such as DIN, BSP, CGA, and JIS.


Industry application
Widely used in photovoltaic, petroleum and petrochemical, laboratory, hydrogen energy, automobile, etc industry More
