R54 Series Tied Diaphragm Regulator
GENTEC R54 Series Single Stage Tied Diaphragm Regulator consists of a specially designed link between the diaphragm and main valve. It is designed to prevent "creep" if contaminants should form on the valve seat.
Features
Single-Stage Configuration
Metal-to-Metal diaphragm to body seal
Integrated waste gas disposal connection for additional safety
Inlet & Outlet Port Size: 1/4" NPT( F )
Bonnet port: 1/8" NPT( F )
Internal Hastelloy valve trim providing an extra measure of
resistance against corrosion ( optional )
