GENTEC R81 Series Steam Heated Vaporizing Regulator
R81 Series Steam Heated Vaporizing Regulator
GENTEC R81 Series Steam Heated Vaporizing Regulator is a diaphragm sensed single-stage regulator designed to heat and/or vaporize a gas or liquid sample before entering an analyzer system.
Features
Metal-to-Metal Seal
Inlet & Outlet Port Size: 1/4" NPT( F )
Steam heating connection
Inlet Port Size: 1/4" NPT( F )
Outlet Port Size: 1/2" NPT( F )
Dimensions
GENTEC R81 Series Steam Heated Vaporizing Regulator
Heating Flow Data
GENTEC R81 Series Steam Heated Vaporizing Regulator
Flow Data
GENTEC R81 Series Steam Heated Vaporizing Regulator
Ordering Information
订购指南
EX: R81SL
Series		 A
Body Ports		 V
Seat		 - D
Inlet Pressure Ranges		 F
Outlet Pressure Ranges		 W
Gauge		 - 00
Inlet Connections		 - 00
Outlet Connections
R81SL
A
V: Vespel®
B: 6000 psi ( 414 bar )
D: 3000 psi ( 206 bar )
E: 1500 psi ( 104 bar )
F: 0-500 psi ( 34 bar )
G: 0-250 psi ( 17 bar )
I: 0-100 psi ( 7 bar )
K: 0-50 psi ( 3 bar )
L: 0-25 psi ( 2 bar )
W: No Gauge
00: 1/4" NPT ( F )
10: 1/8" GENLOK
11: 1/4" GENLOK
15: 6 mm GENLOK
19: 3 mm GENLOK
Other connections available*
00: 1/4" NPT ( F )
10: 1/8" GENLOK
11: 1/4" GENLOK
15: 6 mm GENLOK
19: 3 mm GENLOK
Other connections available*

*: For more connection options contact Gentec.



Industry application
Widely used in photovoltaic, petroleum and petrochemical, laboratory, hydrogen energy, automobile, etc industry More
