| EX: | R21SL
Series |
J
Body Ports |
K
Seat Material |
- D
Inlet Pressure |
I
Outlet Pressure |
P
Gauge |
- C580
Inlet Connections |
- 11
Outet Connections |
- D
Options |
|---|---|---|---|---|---|---|---|---|---|
| R21SL (316L) R21B (Brass) |
A B G J M Q |
K: PCTFE T: PTFE V: Vespel® |
C: 4500 psi (310 bar) D: 3000 psi (206 bar) E: 1500 psi (103 bar) F: 500 psi (34 bar) |
F: 0-500 psi (34 bar) G: 0-250 psi ( 17 bar ) H: 0-150 psi ( 10 bar ) I: 0-100 psi ( 7 bar ) K: 0-50 psi ( 3 bar ) L: 0-25 psi ( 1.5 bar ) Q: 30" Hg Vac-30 psi ( 2 bar ) S: 30" Hg Vac-100 psi ( 7 bar ) T: 30" Hg Vac-200 psi( 14 bar ) |
P: psi / bar K: psi / kPa W: No Gauge |
00: 1/4"NPT(F) C346: CGA346 C320: CGA320 C350: CGA350 C510: CGA510 C540: CGA540 C580: CGA580 C590: CGA590 C326: CGA326 DN05: DIN477 No.5 BS02: BS341 No.2 Other connections available* |
00: 1/4"NPT(F) 01: 1/4"NPT(M) 10: 1/8"GENLOK 11: 1/4"GENLOK 15: 6 mm GENLOK 16: 8 mm GENLOK Other connections available* |
Blank: None P: Panel Mount D: Diaphragm Valve N: Needle Valve R: Relief Valve H: C-22 Diaphragm |
*: For more connection options contact Gentec.
