| EX: | R12SL
Series |
M
Body Ports |
K
Seat |
- D
Inlet Pressure Range |
Q
Outlet Pressure Range |
P
Gauge |
- 00
Inlet Connections |
- 00
Outet Connections |
- R
Options |
|---|---|---|---|---|---|---|---|---|---|
| R12SL |
A B G J M |
K: PCTFE T: PTFE |
D: 3000 psi ( 206 bar ) E: 1500 psi ( 103 bar ) F: 500 psi ( 35 bar ) |
G: 0-250 psi ( 17 bar ) I: 0-100 psi ( 7 bar ) K: 0-50 psi ( 3 bar ) L: 0-25 psi ( 1.5 bar ) M: 0-15 psi ( 1 bar ) Q: 30” Hg Vac-30 psi ( 2 bar ) S: 30" Hg Vac-100 psi( 7 bar ) T: 30" Hg Vac-200 psi( 14 bar ) |
P: psi / bar K: psi / kPa W: No Gauge |
00: 1/4" NPT( F ) C346: CGA346 C320: CGA320 C350: CGA350 C510: CGA510 C540: CGA540 C580: CGA580 C590: CGA590 C326: CGA326 DN05: DIN477 No.5 BS02: BS341 No.2 Other connections available* |
00: 1/4" NPT( F ) 01: 1/4" NPT( M ) 10: 1/8" GENLOK 11: 1/4" GENLOK 12: 3/8" GENLOK 15: 6 mm GENLOK 16: 8 mm GENLOK 14B: 1/4" Hose Barb Other connections available* |
Blank: None D: Diaphragm Valve N: Needle Valve R: Relief Valve |
*: More inlet connection options such as DIN, BSP, CGA, and JIS.
