R17 Series High Flow Regulator

GENTEC R17 Series Stainless Steel Regulator is a diaphragm-sensed single-stage high flow regulator.

Features

Single-Stage Configuration

Inlet & Outlet Port Size: 1" NPT( F )

2" Pressure Gauge

Dimensions

Flow Data

Ordering Information

EX:	R17SL Series	J Body Ports	B Seat	- F Inlet Pressure Range	K Outlet Pressure Ranges	P Gauge	- 08 Inlet Connections	- 08 Outet Connections
	R17SL	A B G J M	P: PU B: NBR	D: 3000 psi ( 206 bar ) F: 500 psi ( 35 bar )	316L Diaphragm G: 0-250 psi ( 17 bar ) H: 0-150 psi ( 10 bar ) I: 0-100 psi ( 7 bar )	P: psi / bar K: psi / kPa W: No Gauge	08: 1" NPT( F ) Other connections available*	08: 1" NPT( F ) Other connections available*
					PTFE Diaphragm J: 0-75 psi ( 5 bar ) K: 0-50 psi ( 3 bar ) L: 0-25 psi ( 1.7 bar ) M: 0-15 psi ( 1 bar ) N: 0-6 psi ( 0.4 bar )
