GENTEC R78 Series Back Pressure Regulator
R78 Series Back Pressure Regulator
GENTEC R78 Series Back Pressure Rugulator is a diaphragm-sensed high purity regulator. The large sensing seat provides a low crack to reseat pressure differential and excellent repeatability.
Features
Metal-to-Metal Seal
Inlet & Outlet Port Size: 1/4" NPT( F )
Dimensions
GENTEC R78 Series Back Pressure Regulator
Flow Data
GENTEC R78 Series Back Pressure Regulator
Ordering Information
订购指南
EX: R78SL
Series		 A
Body Ports		 E
Seat		 - K
Outlet Pressure Ranges		 W
Gauge		 - 00
Inlet Connections		 - 00
Outlet Connections		 - P
Options
R78SL
A
D
E: PEEK
I: 0-100 psi ( 7 bar )
K: 0-50 psi ( 3 bar )
M: 0~15 psi ( 1 bar )
N: 0~6 psi ( 0.4 bar )
P: psi / bar
K: psi / kPa
W: No Gauge
00: 1/4" NPT( F )
Other connections available*
00: 1/4" NPT( F )
Other connections available*
P: Panel Mount

*: For more connection options contact Gentec.



Industry application
Widely used in photovoltaic, petroleum and petrochemical, laboratory, hydrogen energy, automobile, etc industry More
