GENTEC R45 Series High Pressure Regulator
R45 Series High Pressure Regulator
GENTEC R45 Series Ultra High Pressure Single-Stage Regulator is a piston-sensed regulator applicable for highest pressure applications.
Features
Single-Stage Configuration
Inlet & Outlet Port Size: 1/4" NPT( F )
2" Pressure Gauge
Dimensions
GENTEC R45 Series High Pressure Regulator
Flow Data
GENTEC R45 Series High Pressure Regulator
Ordering Information
订购指南
EX: R45SL
Series		 G
Body Ports		 V
Seat		 - B
Inlet Pressure Ranges		 E
Outlet Pressure Ranges		 K
Gauge		 - 00
Inlet Connections		 - 00
Outet Connections
Options
R45SL
A
B
G
J
V: Vespel®
A: 10000 psi ( 690 bar )
B: 6000 psi ( 414 bar )
B: 0-6000 psi ( 414 bar )
C: 0-4500 psi ( 310 bar )
D: 0-3000 psi ( 206 bar )
E: 0-1500 psi ( 103 bar )
P: psi / bar
K: psi / kPa
W: No Gauge
00: 1/4" NPT( F )
C347: CGA347
C677: CGA677
C680: CGA680
DN05: DIN477 No.5
BS02: BS341 No.2
Other connections available*
00: 1/4" NPT( F )
01: 1/4" NPT( M )
10: 1/8" GENLOK
11: 1/4" GENLOK
15: 6 mm GENLOK
16: 8 mm GENLOK
14B: 1/4" Hose Barb
Other connections available*
Blank: None
V: Self relieving ( Venting )

*: More inlet connection options such as DIN, BSP, CGA, and JIS.


Industry application
Widely used in photovoltaic, petroleum and petrochemical, laboratory, hydrogen energy, automobile, etc industry More
