| EX: | R44SL
Series |
M
Body Ports |
K
Seat |
- B
Inlet Pressure Ranges |
D
Outlet Pressure Ranges |
K
Gauge |
- C590
Inlet Connections |
- 11
Outet Connections |
- D
Options |
|---|---|---|---|---|---|---|---|---|---|
| R44SL |
A B G J M |
K: PCTFE |
B: 6000 psi ( 414 bar ) C: 4500 psi ( 310 bar ) D: 3000 psi ( 206 bar ) |
D: 0-3000 psi ( 206 bar ) E: 0-1500 psi ( 103 bar ) F: 0-500 psi ( 35 bar ) G: 0-250 psi ( 17 bar ) |
P: psi / bar K: psi / kPa W: No Gauge |
00: 1/4" NPT( F ) C350: CGA350 C540: CGA540 C580: CGA580 C590: CGA590 C677: CGA677 C680: CGA680 C695: CGA695 DN05: DIN477 No.5 BS02: BS341 No.2 Other connections available* |
00: 1/4" NPT( F ) 01: 1/4" NPT( M ) 10: 1/8" GENLOK 11: 1/4" GENLOK 15: 6 mm GENLOK 16: 8 mm GENLOK 14B: 1/4" Hose Barb Other connections available* |
Blank: None D: Diaphragm Valve N: Needle Valve P: Panel Mount Some valves not available depending on delivery pressures |
*: More inlet connection options such as DIN, BSP, CGA, and JIS.
