 GENTEC HP152T High Purity, Medium Flow Regulator
HP152T High Purity, Medium Flow Regulator
GENTEC HP 152T Series is a Dual-Stage High Purity Brass Regulator designed for high purity applications where a consistent outlet pressure and flow are desired.
Features
2" 316L Stainless Steel Diaphragm
2" Dual-Scale Pressure Gauges
Optional outlet: Needle Valve or Diaphragm Valve
Conforms to CGA E-4 standard for Gas Pressure Regulators
Dimensions
GENTEC HP152T High Purity, Medium Flow Regulator
Flow Data
 GENTEC HP152T High Purity, Medium Flow Regulator
Ordering Information
EX: HP152T
Series
- D
Inlet Pressure Range
I
Outlet Pressure Range
K
Gauge
- C540
Inlet Connections
- 01
Outlet Connections
- NR
Options
HP152T
D: 3000 psi ( 206 bar )
G: 0-250 psi ( 17 bar )
H: 0-150 psi ( 10 bar )
I: 0-100 psi ( 7 bar )
K: 0-50 psi ( 3 bar )
M: 0-15 psi ( 1 bar )
P: psi / bar
K: psi / kPa
W: No Gauge
00: 1/4" NPT( F )
C346: CGA346
C320: CGA320
C350: CGA350
C510: CGA510
C540: CGA540
C580: CGA580
C590: CGA590
C326: CGA326
DN05: DIN477 No.5
BS02: BS341 No.2
Other connections available*
00: 1/4" NPT( F )
01: 1/4" NPT( M )
10: 1/8" GENLOK
11: 1/4" GENLOK
12: 3/8" GENLOK
15: 6 mm GENLOK
16: 8 mm GENLOK
14B: 1/4" Hose Barb
Other connections available*
D: Diaphragm Valve
N: Needle Valve
R: Relief Valve

*: Please see page 83 for more inlet connection options such as DIN, BSP, CGA, and JIS.
