HP152 High Purity, Medium Flow Regulator

GENTEC HP152 Series is a Single-Stage High Purity Brass Regulator designed for high purity applications where occasional readjustment of the working pressure is acceptable.

Features

2" 316L Stainless Steel Diaphragm

2" Dual-Scale Pressure Gauges

Optional outlet: Needle Valve or Diaphragm Valve

Conforms to CGA E-4 standard for Gas Pressure Regulators

Max. Inlet Pressure

3000 psi
Temperature

0˚F ~ 140˚F
Weight

2.65 lb (1.2 kg)

Dimensions

Flow Data

Ordering Information

EX:	HP152 Series	- D Inlet Pressure Range	K Outlet Pressure Range	K Gauge	- C350 Inlet Connections	- 01 Outet Connections	- NR Options
	HP152	D: 3000 psi ( 206 bar )	G: 0-250 psi ( 17 bar ) H: 0-150 psi ( 10 bar ) I: 0-100 psi ( 7 bar ) K: 0-50 psi ( 3 bar ) M: 0-15 psi ( 1 bar )	P: psi / bar K: psi / kPa W: No Gauge	00: 1/4" NPT( F ) C346: CGA346 C320: CGA320 C510: CGA510 C540: CGA540 C580: CGA580 C590: CGA590 C326: CGA326 Other connections available*	00: 1/4" NPT( F ) 01: 1/4" NPT( M ) 10: 1/8" GENLOK 11: 1/4" GENLOK 12: 3/8" GENLOK 15: 6 mm GENLOK 16: 8 mm GENLOK 14B: 1/4" Hose Barb Other connections available*	D: Diaphragm Valve N: Needle Valve R: Relief Valve
		F: 500 psi ( 35 bar )	H: 0-150 psi ( 10 bar ) I: 0-100 psi ( 7 bar ) K: 0-50 psi ( 3 bar ) M: 0-15 psi ( 1 bar )	P: psi / bar K: psi / kPa W: No Gauge	C510: CGA510 C300: CGA300 Other connections available*	Same as above	D: Diaphragm Valve N: Needle Valve R: Relief Valve
